ROAD TANDEM BIKE
Handmade and fully customizable two-seater road tandem bike
COMPONENTS AND CHARACTERISTICS
Below you will find all the technical details and specifications of our road tandems. Both the frame and components are 100% customizable. The price of the components is added to the final price of our frame.
TECHNICAL DETAILS
ELECTRIC DETAILS
COMPONENTS PACK BASIC
COMPONENTS PACK MEDIUM
COMPONENTS PACK PREMIUM
TECHNICAL DETAILS
Frame specifications
- 7000 series aluminium frame handcrafted in Tarragona
- TIG welding, option of polished aluminium welds (additional cost)
- SRAM UDH detachable dropouts and brake caliper support and CNC machined pointers
- Custom size for pilot and co-pilot
- Multi-size option for tandems with multiple riders. Suitable for riders between 165 and 185cm
- Colour with contrasting logos to be chosen
- Multicolour option, more than two colours, or special design at an additional cost
- Standard frame width 142mm (optional: 148mm Boost size)
- Suitable for Boost wheel 29 x 2.6” maximum
Rear dropouts and brake caliper
- Proprietary “flat mount” system with the option of mounting “post mount”
- Direct P/M support for 203mm disc
Wheel arch and bottom bracket
- 50mm wheel arch (optional: up to 73mm)
- 31.6mm diameter seat posts
- Option to add rack support holes
- 68mm BSA bottom bracket
Steering
- Integrated tapered steering (1 1/8″ – 1 1/2″)
- Internal routing of shift and brake wiring
Transmission and rear stem
- External Campmajó transmission system
- Anchorage ISCG05 in the BSA crank set with chain guide-crankcase to adjust the timing chain
- Adjustable rear Campmajó stem
Other
- 5 year guarantee against manufacturing defects
- Total tandem weight, including frame and components, 14kg
- Option to add up to a maximum of 5 bottle cages mounts
ELECTRIC DETAILS
- OLI E-Bike Systems Edge-SH motor 250W & 90Nm
- Removable and integrated OLI battery of 630Wh
- Motor & battery are integrated in the lower and central part of the frame – to make sure to give the greatest possible stability, comfort and safety when taking curves and maintaining balance
- Option to include a support for an external 468Wh battery
- Electric tandem total weight: from 21kg
COMPONENTS PACK BASIC
Wheels: Gurpil
Tires: Maxxis Dolomites 28C
Brakes: Shimano 105
Gearshifter: Shimano 105 – 11 x 2v
Cassette: Sunrace – 11v
Chains: KMC
Cranks: Sram SX Eagle
Spiders: Campmajó
Bottom bracket: Shimano Hollowtech II
Plates: TA
Handlebar: Top Fun Carbon/Alu
Stem: PRO LT 6°
Rear stem: Campmajó rigid
Steering: Neco integrated
Fork: Top Fun Carbon/Alu
Seats: Selle San Remo
Seat posts: UNO Alu
TOTAL PRICE BASIC COMPONENTS PACK (including VAT): €2,500
COMPONENTS PACK MEDIUM
Wheels: GTR
Tires: Maxxis High Road 28C
Brakes: Shimano Ultegra
Gearshifter: Shimano Ultegra – 11 x 2v
Cassette: Sunrace – 11v
Chains: KMC
Cranks: Shimano SLX
Spiders: Campmajó
Bottom bracket: Shimano Hollowtech II
Plates: TA
Handlebar: PRO Road Alloy
Stem: PRO LT 6°
Rear stem: Campmajó adjustable
Steering: First integrated
Fork: Top Fun Carbon/Alu
Seats: PRO Turnix Crmo
Seat posts: PRO LT
TOTAL PRICE MEDIUM COMPONENTS PACK (including VAT): €3,250
COMPONENTS PACK PREMIUM
Wheels: GTR
Tires: Maxxis High Road 28C
Brakes: Shimano Dura-Ace
Gearshifter: Shimano Dura-Ace – 11 x 2v
Cassette: Sunrace – 11v
Chains: KMC
Cranks: Shimano Deore XT
Spiders: Campmajó
Bottom bracket: Shimano Hollowtech II
Plates: TA
Handlebar: Ritchey WCS
Stem: Ritchey WCS
Rear stem: Campmajó adjustable
Steering: Ritchey WCS integrated
Fork: Dedacciai Full Carbon F64
Seats: PRO Stealth Team
Seat posts: Ritchey WCS 1-Bolt
TOTAL PRICE PREMIUM COMPONENTS PACK (including VAT): €4,750
Do you like the pure white tandem in the photos?
Read the article and download the technical sheet:
ROAD TANDEM FRAME
Road tandem frame
- Aluminium frame
- Frame painting (1 frame colour + 1 logo colour)
- “Bikefitting” geometry design
- VAT included, packaging and shipping not included
PRICE
2.000€
ROAD E-TANDEM FRAME
Road electric tandem frame
- Aluminium frame and primary drivetrain
- Engine OLI Edge-SH 250WW, 90NW and an integrated removable OLI 630Wh battery
- “Bikefitting” geometry design
- Frame painting (1 frame colour + 1 logo colour)
- VAT included, packaging and shipping not included
PRICE
5.100€
FULL ROAD TANDEM
Complete aluminium road tandem
- Aluminium frame
- “Bikefitting” geometry design
- Frame painting (1 frame colour + 1 logo colour)
- Full components pack
- Assembly of chosen components
- VAT included, packaging and shipping not included
BASIC PACK
€4,500
MEDIUM PACK
€5,250
PREMIUM PACK
€6,750
FULL ROAD E-TANDEM
Complete aluminium road electric tandem
- Aluminium frame
- OLI Edge-SH 250WW, 90NW motor and an integrated removable OLI 630Wh battery
- Frame painting (1 frame colour + 1 logo colour)
- “Bikefitting” geometry design
- Full components pack
- Assembly of chosen components
- VAT included, packaging and shipping not included
BASIC PACK
€7,500
MEDIUM PACK
€8,250
PREMIUM PACK
€9,750
Fill out your form and we’ll send you your detailed quote along with the preliminary design of your tandem!
Note
Our products are in constant development, which is why it is possible that the current models already have differences and improvements compared to the ones you have seen as an example in the photographs on the page.
WHY CAMPMAJÓ?
Our aluminum road tandems are known for their combination of strength and lightness, resulting in an agile and high-performance tandem. Thanks to their stiffness and responsiveness, our aluminum tandems will allow you to reach high speeds and enjoy a smooth and efficient driving experience on the roads.
The trust placed in our brand by elite cyclists evidences the exceptional quality and performance of our road tandems. Our dedication to innovation and constant improvement drives us to continue to lead this sector.
Moreover, now with the electric component, you will have extra energy to cover longer distances without worrying about fatigue. Opening up new possibilities for exploration and adventure on the road, allowing you to discover new and challenging places that previously might have been inaccessible.
Join the community of passionate cyclists and experience the thrill of hitting the roads on a tandem made just for you.
Share the excitement of the road!
EXTERNAL DRIVETRAIN SYSTEM
Our tandems are equipped with an external transmission system, of our own design. In this system, the primary 1:1 transmission is built externaly. This way we avoid the most common chain problems in conventional tandems.
In order to mount this system and maintain the correct chain line, we manufacture the spiders ourselves. This is why we always mount “direct mount” cranks.
REAR SPIDER
Road tandems use a double chainring, with this 110mm bcd double spider we manage to unify the three plates with the cranks.
The outer plate is fixed with a 1:1 ratio to the front plate. The two inner plates with different development are what transmit the pedaling force to the rear wheel. With the change of gears the position of one or the other is changed just like on a bicycle.
FRONT SPIDER
For the front driveline we use a simple 104mm bcd spider.
CHAIN TENSIONER
Our tandems carry our own tensioning system consisting of an Anchorage ISCG05 tensioner with an 11T jocker wheel. This system is much more practical than the conventional eccentric system.
1 – Easier to adjust, no need to remove the cranks
2 – You can tighten the chain without changing the geometry
3 – By tensioning upwards, the chain is more protected
4 – Easier to find the right tension
At Campmajó we have been developing our own chain tensioner for years and it works amazing! Even for our competition models.
ADJUSTABLE REAR STEM
To ensure maximum rider comfort, we manufacture our own adjustable stocker stem for our tandems. In this system the same stem clamp is the one that fixes the captain seat post. In this way it is possible to adjust the height of the seat without changing the stocker handlebar position. The handlebar position is adjusted with the adjustable system of the stem itself.
This system is very comfortable in general, but especially when it comes to a tandem that changes riders regularly.
OUR COMPONENTS
DOUBLE SPIDER
€97
Bcd 110mm
Shimano o Sram spline
SIMPLE SPIDER
€54
Bcd 104mm
Shimano o Sram spline
TENSIONER
€85
Anchorage ISCG05
Jocker wheel included
ADJUSTABLE STEM
€180
Customizable colour
CUSTOMIZE YOUR TANDEM
Our tandems are fully customizable. Thanks to our artisan work methodology, we are specialists in adapting our products to the physical needs and aesthetic preferences of each of our customers.
OUR LATEST ROAD TANDEMS
Below are some examples of our road tandems. Each of them has been customized to the last detail with different types of paint, components and sizes. 100% aligned to our customers’ preferences
ASTUMA WHITE ROAD TANDEM
ASTUMA GREEN ROAD TANDEM
BLUE & BLACK ROAD TANDEM
